Bellota Disc blades range — ref. NOTCHED
Main product specifications
| ø " | C | Grs | N | D |
|---|---|---|---|---|
| 16" | 3 | 2490 | 100 | 16 |
| 16" | 3,5 | 2880 | 100 | 16 |
| 16" | 4 | 3320 | 100 | 16 |
| 16" | 4,5 | 3720 | 100 | 16 |
| 16" | 5 | 4110 | 100 | 16 |
| 18" | 3,5 | 3650 | 100 | 16 |
| 18" | 4 | 4200 | 100 | 16 |
| 18" | 4,5 | 4740 | 100 | 16 |
| 18" | 5 | 5210 | 100 | 16 |
| 18" | 6 | 6180 | 100 | 16 |
| 20" | 3,5 | 4860 | 100 | 16 |
| 20" | 4 | 5570 | 100 | 16 |
| 20" | 4,5 | 6270 | 100 | 16 |
| 20" | 5 | 6890 | 100 | 16 |
| 20" | 6 | 8160 | 100 | 16 |
| 22" | 4 | 6930 | 100 | 14 |
| 22" | 4,5 | 7810 | 100 | 14 |
| 22" | 5 | 8590 | 100 | 14 |
| 22" | 6 | 10190 | 100 | 14 |
| 24" | 4,5 | 9440 | 100 | 14 |
| 24" | 5 | 10390 | 100 | 14 |
| 24" | 6 | 12350 | 50 | 14 |
| 24" | 7 | 14480 | 50 | 14 |
| 24" | 8 | 16640 | 50 | 14 |
| 26" | 5 | 12490 | 50 | 12 |
| 26" | 6 | 15000 | 50 | 12 |
| 26" | 7 | 17490 | 50 | 12 |
| 26" | 8 | 19940 | 50 | 12 |
| 28" | 6 | 17780 | 50 | 12 |
| 28" | 7 | 20730 | 50 | 12 |
| 28" | 8 | 23650 | 40 | 12 |
| 30" | 6 | 20400 | 25 | 10 |
| 30" | 8 | 27160 | 25 | 10 |
| 30" | 10 | 33400 | 20 | 10 |
| 32" | 8 | 31680 | 20 | 10 |
| 32" | 10 | 39000 | 20 | 10 |
| 34" | 12 | 59600 | 15 | 10 |
| 36" | 12 | 63550 | 15 | 10 |
D Made-to-order products.
Any kind of disc may be manufactured as plain or notched
